More Power for Commercial Cooling
Commercial cooling applications require strong and durable fins. Our pneumatic fin forming machine is designed to deliver the necessary performance. It is suitable for cabinet air conditioner outdoor units and small chiller radiators, and supports wave-type and staggered fin designs.
Its key advantage is higher stamping force compared to standard machines, enabling the processing of stainless steel and titanium. The machine is equipped with a hydraulic overload protection system that activates when hard spots occur, preventing potential damage.
Our 41-person team is committed to quality, ensuring that every unit operates smoothly. This machine expands your clients' production capabilities.
Practical Line for Reliable Output
The production line is designed for efficiency and reliability. It connects to two automatic unwinders, allowing continuous operation through roll switching. The coil first passes through a leveling device, followed by a servo feeder with ±0.01 mm accuracy, which feeds the material into the forming section.
Electric cylinders drive the dies, and the fin pitch can be adjusted between 4–12 mm after stamping. An online inspection system detects any burrs, and qualified parts proceed to the cutting stage. This machine ensures consistent and reliable output throughout each shift.
User-Friendly Operation
Ease of use is a key feature of this machine. The fin width range is 120–345 mm, with fin height precision of ±0.03 mm. Heat exchange efficiency is improved by 3–5% compared to standard machines.
A touchscreen control system simplifies operation, and die changes can be completed in under 30 minutes. Noise levels remain below 68 dB, meeting common environmental standards.
We offer a one-year warranty, and our service team responds within 48 hours. Backed by 18 years of manufacturing experience, this machine is a reliable partner for your business.
Product Specifications
|
Parameter |
Specification |
|
Model |
Pneumatic Fin Forming Machine |
|
Material |
Aluminum, Copper, Stainless Steel, Titanium |
|
Fin Type |
Wave-type, Staggered |
|
Fin Width Range |
120–345 mm |
|
Fin Height Precision |
±0.03 mm |
|
Pitch Range |
4–12 mm |
|
Servo Feed Accuracy |
±0.01 mm |
|
Noise Level |
<68 dB |
|
Warranty |
1 year |
|
Service Response |
Within 48 hours |
